Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length

Good quality Soluble Dietary Fiber for sales
Good quality Soluble Dietary Fiber for sales
I'm Online Chat Now

Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length

China Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length supplier
Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length supplier Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length supplier Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length supplier Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length supplier

Large Image :  Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length

Product Details:

Place of Origin: ANHUI,CHINA
Brand Name: ELITE-INDUS
Certification: ISO/CE
Model Number: ELT-HEG

Payment & Shipping Terms:

Minimum Order Quantity: 1000KGS
Price: Negotiation
Packaging Details: 20kg/Bag, 1.2Ton/Pallets, total 20Pallets,24Ton/20'gp
Delivery Time: Within 15days after order confirmation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000/Month
Contact Now
Detailed Product Description
Material: High Quality High Speed Wire Density: 7800KG/m3
Type: Hooked End Glued Length: 60MM
Diameter: 0.75MM Tensile Strength: Min 1160Mpa
L/D: 80

Low Carbon Cold drawn hooked end Steel Fiber Dramix 3D 80/60 BG



1, Steel Fiber Introduction:

ELT steel macro-fibers will also improve impact, shatter, fatigue and abrasion resistance while increasing toughness of concrete.

Dosage rates will vary depending upon the reinforcing requirements and can range from 15 to 60 kg/m³.

ELT STEEL FIBER complies with ASTM C1116, Standard Specification for Fiber Reinforced Concrete and Shotcrete and ASTM A820,

Type I fiber, Standard Specification for Steel Fibers for Fiber Reinforced Concrete.
ELT STEEL FIBER is a low carbon, cold-drawn and hooked-end steel wire fiber designed to provide concrete with temperature and

shrinkage crack control, enhanced flexural reinforcement, improved shear strength and increase the crack resistance of concrete.

The fiber can loosed or glued.

Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length



2, Steel Fiber Standard:


Conforming to the provisions of ASTM A820.Type 1 (Drawn Wire)



Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length


3, Steel Fiber Functions:

  • Increases impact, shatter and abrasion resistance of concrete
  • Reduces segregation, plastic settlement, and shrinkage cracking of concrete
  • Provides three-dimensional reinforcement against macro-cracking
  • Increases overall durability, fatigue resistance and flexural toughness
  • Reduction of in-place cost versus wire mesh for temperature / shrinkage crack control
  • Easily added to concrete mixture at any time prior to placement


4, Steel Fiber Application:

  • Commercial and industrial slabs on ground
  • Bridge decks, overlays and pavements
  • Precast concrete applications and slabs on pile
  • Shotcrete, tunnel linings and slope stabilization
  • Mass concrete and composite deck construction



Packing:

Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length



5,Specification:



Model

Length

MM

Diameter

MM

Draw Ratio

(L/D)

Tensile Strength

MPA

Kilograms Per

Cubic Meter

ELT 70/55 55 0.8 70 ≥1000 4400
ELT 80/60 60 0.75 80 ≥1000 4600
ELT 50/38 38 0.75 50 ≥1000 7300
ELT 45/35 35 0.75 45 ≥1000 7900
ELT 45/30 30 0.65 45 ≥1000 12500
ELT 100/60 60 0.62 100 ≥1000 6800
ELT 80/50 50 0.62 80 ≥1000 8100
ELT 55/35 35 0.62 55 ≥1000 11800
ELT 50/30 30 0.62 50 ≥1000 13500
ELT 65/35 35 0.55 65 ≥1000 14500



6, Typical Application


It is a kind of special metal steel fibre, has high compressive strength, tensile strength,crack resistance

and is widely used in high iron casting, RPC cover plate, important projects components and external rendering.



It can also greatly improve anti-tensile,
anti-compressive, anti-shear intensity, impermeability, impact resistance and fatigue
resistance, etc.



Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length



7, Our Company:



Anhui Elite Industrial Co.,LTD was established in 2007, has become one of the leading and professional suppliers of all kinds

of Concrete additivein the world market.



Our Product were widely used in all kinds of concrete,mortar,plaster projects and exported

to more than 30 countries, Such as USA,Russia, Germany, Australia, Chile, UAE, Korea, Vietnam, Africa etc.



Our Product was made by 100% Virgin Material with advanced equipment , we have one full set of precise testing instrument,

testing equipment andquality inspection team, technology research and development team. the management system was

certified by ISO9001 and our products have been passed the CE Certification.



Our Mainly Product and Production Capacity as below:



Main Item
Capacity/Annual
Polypropylene Fiber (PP Fiber)
15000mts
Polyester Fiber (PET Fiber)
6000mts
Polyvinyl Alcohol Fiber ( PVA Fiber)
30000mts
Polyacrylonitrile Fiber (PAN Fiber)
6000mts
Naphthalene Formaldehyde Sulphonate
300000mts
Polycarboxylate Superplasticizer (Flake/Powder/Liquid)
150000mts
Foam Agent
30000mts



8, Related Product:

Hooked End Glued Concrete Reinforcement Fiber 7800KG/M3 Density 60MM Length
