Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement

Good quality Soluble Dietary Fiber for sales
Good quality Soluble Dietary Fiber for sales
I'm Online Chat Now

Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement

China Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement supplier
Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement supplier Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement supplier Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement supplier Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement supplier Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement supplier Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement supplier

Large Image :  Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement

Product Details:

Place of Origin: ANHUI,CHINA
Brand Name: ELITE-INDUS
Certification: ISO/CE
Model Number: ELT-HEG

Payment & Shipping Terms:

Minimum Order Quantity: 1000KGS
Price: Negotiation
Packaging Details: 20kg/Bag, 1.2Ton/Pallets, total 20Pallets,24Ton/20'gp
Delivery Time: Within 15days after order confirmation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000/Month
Contact Now
Detailed Product Description
Material: Cold Drawn Steel Wire Density: 7800KG/m3
Length: 35 MM Diameter: 0.54mm
Certificate: ISO/CE Tensile Strength: 1000MPa
Standard: ASTM C1116/ASTM A820 Anchorage: Hooked End
Draw Ratio (L/D): 65

     Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement



1,Steel Fiber Introduction:

Elt steel fibers are designed specifically for the reinforcement of concrete, and shotcrete mixes. ELT Steel Fiber is a cold

drawn collated hooked end steel fiber, to provide optimum anchorage within the concrete. ELT steel fibers are specifically

designed to meet or exceed the defined performance requirements.



Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement



2,Steel Fiber Standard:


Conforming to the provisions of ASTM A820.Type 1 (Drawn Wire)

Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement

3,Features & Benefits

  • Increases impact,shatter and abrasion resistance of concrete
  • Reduces segregation,plastic settlement,and shrinkage cracking of concrete
  • Provides three-dimensional reinforcement against macro-cracking
  • Increases overall durability, fatigue resistance and flexural toughness
  • Reduction of in-place cost versus wire mesh for temperature / shrinkage crack control
  • Easily added to concrete mixture at any time prior to placement

4, Packing:

Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement

5,Specification:



Model

Length

MM

Diameter

MM

Draw Ratio

(L/D)

Tensile Strength

MPA

Kilograms Per Cubic Meter
ELT 70/55 55 0.8 70 ≥1000 4400
ELT 80/60 60 0.75 80 ≥1000 4600
ELT 50/38 38 0.75 50 ≥1000 7300
ELT 45/35 35 0.75 45 ≥1000 7900
ELT 45/30 30 0.65 45 ≥1000 12500
ELT 100/60 60 0.62 100 ≥1000 6800
ELT 80/50 50 0.62 80 ≥1000 8100
ELT 55/35 35 0.62 55 ≥1000 11800
ELT 50/30 30 0.62 50 ≥1000 13500
ELT 65/35 35 0.55 65 ≥1000 14500

Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement

6,Typical Application

  • Commercial and industrial slabs on ground
  • Bridge decks, overlays and pavements
  • Precast concrete applications and slabs on pile
  • Shotcrete, tunnel linings and slope stabilization
  • Mass concrete and composite deck construction

Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement

7, Our Company:

Anhui Elite Industrial Co.,LTD was established in 2007, has become one of the leading and professional suppliers of all kinds

of Concrete additivein the world market.Our Product were widely used in all kinds of concrete,mortar,plaster projects and exported

to more than 30 countries, Such as USA,Russia, Germany, Australia, Chile, UAE, Korea, Vietnam, Africa etc.

Our Product was made by 100% Virgin Material with advanced equipment , we have one full set of precise testing instrument,

testing equipment andquality inspection team, technology research and development team. the management system was

certified by ISO9001 and our products have been passed the CE Certification.



Our Mainly Product and Production Capacity as below:



Main Item
Capacity/Annual
Polypropylene Fiber (PP Fiber)
15000mts
Polyester Fiber(PET Fiber)
6000mts
Polyvinyl Alcohol Fiber( PVA Fiber)
30000mts
Polyacrylonitrile Fiber(PAN Fiber)
6000mts
Naphthalene Formaldehyde Sulphonate
300000mts
Polycarboxylate Superplasticizer(Flake/Powder/Liquid)
150000mts
Foam Agent
30000mts



8, Related Product:

Cold Drawn Collated Hooked End Steel Fiber NOVOCON CHE5535 For Concrete Reinforcement
