Plastic Textured Geocell Retaining Wall with 50Mm 75Mm 100Mm 150Mm 200Mm 250Mm Height

Minimum Order Quantity : 1000m2 Price : Negotiation
Packaging Details : one set a packing on pallet Payment Terms : L/C, D/P, T/T,
Supply Ability : 6000m2 a day
Place of Origin: Anhui, China Brand Name: Elite-Indus
Certification: ISO, CE Model Number: Eltcell-0023

Detail Information

Material: HDPE Color: Black, Green, Sand Color, Brown
Height: 50mm To 300mm Welding Distance: 220mm To 1600mm
Tensile Strength: 1200mpa Min. Or 1450mpa Min. Surface: Textured Or Smooth
Thickness: 0.9-1.7mm
High Light:

envirogrid geocell

,

plastic geocell

Product Description

50Mm 75Mm 100Mm 150Mm 200Mm 250Mm Height American Astm Standard Geocll For Soil Stabilization



HDPE Geocell Introduction :



It was made of a new type of high-strength geosynthetics, which welding the strengthened HDPE sheets by the high-power ultra-sonic and forming to be a structure of three-dimensional reticular formation.



Easily folding and convenient for transportation. For construction, the geocell can be pull into a network and launched into a three-dimensional honeycomb grid.



As it was filled in soil, macadam, concrete or other granular materials, constituted to be a construction, which has strong sidewise restraint and high rate of stiffness.





HDPE Geocell Production Process:



Plastic Textured Geocell Retaining Wall with 50Mm 75Mm 100Mm 150Mm 200Mm 250Mm Height 0

HDPE Geocell Applications:



¨ Load Support

¨ Slope Protection

¨ Retaining Wall

¨ Channel Protection

¨ Ground Stabilization

¨ Erosion control



Plastic Textured Geocell Retaining Wall with 50Mm 75Mm 100Mm 150Mm 200Mm 250Mm Height 1







HDPE Geocell Specifications



Item No. Height
(mm)
Weld distance
(mm)

Thickness

of the Sheet
(mm)

Tensile Strength of Welding Points
(N/cm)
GC5/40 50 330≤A<1000 ≥1.1 ≥100
GC7.5/40 75 330≤A<1000 ≥1.1 ≥100
GC10/40 100 330≤A<1000 ≥1.1 ≥100
GC15/40 150 330≤A<1000 ≥1.1 ≥100
GC20/40 200 330≤A<1000 ≥1.1 ≥100
GC20/33 200 330 1.25+/-0.05 ≥100
GC20/60 200 600 1.50+/-0.05 ≥100
GC20/60 200 600 1.25+/-0.05 ≥100

Remarks: Width of the product can be made according to the customer’s demand,

and other special standards will carry out by agreement or contract.



HDPE Geocell Testing



Plastic Textured Geocell Retaining Wall with 50Mm 75Mm 100Mm 150Mm 200Mm 250Mm Height 2





HDPE Geocell Packing:



Plastic Textured Geocell Retaining Wall with 50Mm 75Mm 100Mm 150Mm 200Mm 250Mm Height 3
