Polypropylene Polymer Synthetic MacroFiber For Concrete Reinforcement
Contact Person : Jack
Phone Number : 0086-13955140199
WhatsApp : +8613955140199
| Minimum Order Quantity : | 1000kgs | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | 5kgs/water soluble paper carton, total 1200-1300kg/pallet, 12800kg/20'GP, 25800kg/40'GP | Delivery Time : | Within 15days after order confirmation |
| Payment Terms : | L/C, D/A, D/P, T/T, , MoneyGram | Supply Ability : | 10000TON PER YEARS |
| Place of Origin: | Anhui | Brand Name: | ELITE-INDUE |
|---|---|---|---|
| Certification: | CE ISO | Model Number: | Elt-Embossed |
|
Detail Information |
|||
| Material: | Virgin Blended Copolymer | Length: | 48mm 55mm 65mm |
|---|---|---|---|
| Elastic Modulas: | 9000MPa-10000MPA | Equivalent Diameter: | 0.8mm+/-0.2 |
| Melting Point(C Deg.): | 160 - 170 | Density(g/cm3): | 0.91+/-0.01 |
| Tensile Strength(MPa): | 500-800Mpa | Acid &Alkali Resistance: | Excellent |
| Color: | White/GRAY/Transparent | Application: | Concrete Additives Concrete Admixture |
| High Light: | monofilament polypropylene fiber,cement monofilament polypropylene fiber,48mm monofilament polypropylene fiber |
||
Product Description
Concrete Additives Concrete Admixture Macro Synthetic Fiber Embossed Wave Type
1, Description:
ELT-EMBOSSED fibers comply with ASTM C1116, Standard Specification for Fiber Reinforced Concrete and Shotcrete, and are specifically used
to improve impact, shatter and abrasion resistance, to increase fatigue resistance, to increase toughness of concrete and provide long term durability
of concrete and cement based building products. Dosage rates will vary depending upon the reinforcing requirements and can range typically from 2 to 6kg/m³.
ELT-EMBOSSED is a Structural macro synthetic fiber engineered for use as an alternate to steel fibers and welded wire mesh for precast concrete
and shotcrete reinforcement applications.
2,Specification:
| Raw Material | Virgin grade polypropylene | Tensile Strength(MPa): | 550 min. |
| Water Absorbency: | No | Density(g/cm3) : | 0.91+/-0.01 |
| Melting Point(C Deg.) | 160 - 170 | Elastic Modulas(Mpa): | 9000 min |
| Acid & Alkali Resistance | Excellent | Equivalent Diameter | 0.8mm |
| Moisture Content | 0.0% | Fiber Type | Embossed |
| Color | White, Black, Gray,Natural | ||
| Length: | 30mm,48mm, 55mm, 60mm,65mm or as per request | ||
| Tandard Dosage | 2kg/m3 to 6kg/m3 | ||
3, Packing & Delivery:
Packing: 120-140g/ water soluble film bundle, 5kgs/water soluble paper carton
total 1200-1300kg/pallet, 12800kg/20’ container, 25800kg/40’ container
| Delivery Time | 3-15 days after deposit (we always keep inventory) |
| Sample Time | 1-3 days after confirmation |
| Production Time | 7-15days |
| Payment Methods | T/T, L/C, or as per negotiate |
Compared with steel fiber, our fiber has the advantages of anti-corrosion and wear-resistant reducing 50% cost with same volume to steel fiber.
1), Equivalent strengths to WWM and rebar provided by engineering calculations;
2), Controls and mitigates plastic shrinkage cracking and reduces segregation and bleed-water;
3), Provides three-dimensional reinforcement against micro and macro-cracking;
4), Reduces equipment wear, fiber rebound and increases build-up thickness compared to steel fibers for shotcrete applications;
5), Increases overall durability, fatigue resistance and flexural toughness;
6), Reduction of in-place cost versus wire mesh for temperature / shrinkage crack control;
7), Easily added to concrete mixture at any time prior to placement;
8), Tested in accordance with ASTM C 1116, EN14889-2.
5, Application:
■ Industrial and Warehouse Floors
■ Residential and commercial Slab on grade
■ Driveways and side walks
■ Replacement for welded wire fabric (WWF)
■ Composite metal decks and parking structures
■ Septic tanks,manholes and burial vaults
■ Precast elements
■ Shotcrete applications
6, CERTIFICATION:
Our Fibers was made by 100% Virgin Material with advanced equipment of yard and cutting, we have one full set of precise testing
instrument, testing equipment and quality inspection team, technology research and development team. the management system
was certified by ISO9001 and our products have been passed the CE Certification.
