Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction

Basic Information
Place of Origin: ANHUI,CHINA
Brand Name: ELITE-INDUS
Certification: ISO/CE
Model Number: ELT-FGRID
Minimum Order Quantity: 10000m2
Price: USD0.35/m2 to USD1.5/m2
Packaging Details: Width 3.95M X Length 100M per roll in PE film bag
Delivery Time: within 15 days after order confirmation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000m2/days

            Warp Knitted Self Adhesive Fiberglass Geogrids Coating With Asphalt For Road Construction



1, Description:



EltGrid-FGG Fiberglass geogrid is a kind of product that uses excellent reinforced non-alkali fiberglass yarn as material.

It is adopted warp knitting directive texture as mesh substrate, and warp knitted on the modern imported warp-knitting machine.



Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction

Coating with high quality modified asphalt, the geogrid has high tensile strength, tearing resistance, good creep resistance.

This geogrid is mainly used in new road,soft road surface to enlarge the loading capacity and road maintaince to prevent the road crackle.



2,Product Features:

1,fiberglass geogrid have Light weight, high tensile strength, high modulus, low elongation and good toughness.
2,Corrosion resistance, no long-term creep, long life span.
3,Good physical and chemical stability and good thermal stability.
4,Resistant to fatigue cracking, high-temperature track and low temperature shrinkage cracking.
5,fiberglass geogrid can Delaying and decreasing crack reflection.



3, Production Process:



Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction

Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction



4,Specification:


Item
(Standard:GB/T21825-2008)
FGG
30X30
FGG
50X50
FGG
80X80
FGG
100X100
FGG
120X120
FGG
150X150
FGG
200X200
FGG
300X300
Mesh Size TD/MD, MM
12.7mmX12.7mm, 25.4mmX25.4mm
Tensile Strength TD, KN/M
30
50
80
100
120
150
200
300
Tensile Strength MD, KN/M
30
50
80
100
120
150
200
300
Elongation TD, %
4
4
4
4
4
4
4
4
Elongation MD, %
4
4
4
4
4
4
4
4
Width, M
1M to 6M, normal is 3.95M and 5.8M
Length, M
Normal is 50M or 100M or as per your request
Note
1, All type fiberglass geogrid can composite 17g/m2 to 200g/m2 PET or PP Geotextile
2, All type fiberglass geogrid can self Adhesive



5, Packing:

Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction



Normal packing is Width 3.95M X Length 50M/100m Per Roll In PE Film Bag

Or Width 5.8M X Length 50M/100m Per Roll In PE Film Bag



6,Test:

Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction

7, Application:



Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction

1. It reinforces old asphalt concrete road surface and asphalt surface layer, and prevents damage;
2. It is used for rebuilding cement concrete road surface into composite road surface and restraining reflection caused by

lock contraction;
3. It is used in road expansion and improvement project and crack caused by old combination position and uneven sedimentation;
4. It is used in soft soil base reinforcement treatment, is favorable for soft soil water separation and concretion, restrains

sedimentation effectively, distributes stress uniformly and improve overall strength.
5. It is used for prevention contraction crack caused by new rode semi-rigid base layer, and reinforcing and preventing road

surface crack used by foundation crack reflection.



Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction

Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction

Warp Knitted Self Adhesive Fiberglass Geogrid With Asphalt For Road Construction



8, Our Company:

ANHUI ELITE INDUSTRIAL CO.,LTD
ELITE was established in 2007, has become one of the leading and professional suppliers of many kinds of Geosynthetics
(Geotextile,Geomembrane, Geogrid,Geocell, GCL,Geocomposite) in the world market.

ELITE equipements are mainly import from Germany, Italy, Cabada, France. We have one full set of precise testing instrument
and quality inspection team, technology research & Development team.
