Needle Punched Non Woven Fabric , High Strength Non Woven Polypropylene Geotextile

Name: Needle Punched Non Woven Fabric , High Strength Non Woven Polypropylene Geotextile
Brand: ANHUI ELITE INDUSTRIAL CO.,LTD
SKU: EltTex-NWHPP
Availability: InStock

Specifications

Highlight:

non woven needle punched geotextile

,

pp woven geotextile

Material:

High Strength PP Short Fiber

Unit Weight:

100g/m2 To 1200g/m2

Width:

1M To 8M

Length:

50M/100M Or As Per Your Request

Color:

Black Color With Anti UV

Certificate:

ISO

HS Code:

5603949000

Tags:

non woven geotextile

non woven needle punched geotextile

Key Attributes

Brand Name: Elite-Indus

Model Number: EltTex-NWHPP

Place of Origin: Anhui

Certification: ISO CE

Minimum Order Quantity: 1000M2

Price: Negotiation

Supply Ability: 100000M2/day

Delivery Time: Within 15days after order confirmation

Payment Terms: L/C, D/A, D/P, T/T, ,

Standard Packaging: Width 5.8M X Length 50M/100M per roll in Black Plastic Woven Bag

Product Description

Short Fiber Needle Punched High Strength Polypropylene Nonwoven Geotextile

--------EltTex-NWHPP

Introduction:

EltTex-NWWHPP geotextile is made of High Strength Polypropylene Short Fiber. It is production process include fluffing, comb, mix, laying then needle punched.NWHPP Geotextile has not only the superior features as NWPP Geotextile does but also provides High Tensile Strength.

Technical Specification:

No.	Item		Unit	Index
No.	Item		Unit	100	150	200	300	400	500	600
1	Unit area quality		g/m²	100(1±6%)	150(1±6%)	200(1±6%)	300(1±6%)	400(1±6%)	500(1±6%)	600(1±6%)
2	grab strength	MD	N ≥	350	575	800	1100	1500	2000	2400
2	grab strength	TD	N ≥	350	575	800	1100	1500	2000	2400
3	grab strength elongation	MD	%	60~80	60~80	60~85	50~100	50~100	50~100	50~100
3	grab strength elongation	TD	%	50~70	50~70	50~75	50~100	50~100	50~100	50~100
4	Tear strength	MD	N ≥	100	225	350	420	500	580	660
4	Tear strength	TD	N ≥	100	225	350	420	500	580	660
5	CBR Strength		KN ≥	1.3	1.65	2	3.5	4.3	5.5	6.5
6	Breaking strength	MD	KN ≥	5	8	11	16	22	28	35
6	Breaking strength	TD	KN ≥	5	8	11	16	22	28	35
7	Elongation at Break	MD	%	40~75	40~75	40~75	40~80	50~90	50~90	50~90
7	Elongation at Break	TD	%	45~65	45~65	45~65	45~70	50~90	50~90	50~90
8	Break Elongation at 50N	MD	%	3~6	3~6	3~6	3~6	3~6	3~6	3~6
8	Break Elongation at 50N	TD	%	3~6	3~6	3~6	3~6	3~6	3~6	3~6
9	Puncture strength		N≥	200	315	430	650	900	1200	1500
10	Thickness		mm	1.4~1.7	1.6~1.95	1.8~2.2	2.4~2.8	3.0~3.5	3.6~4.0	4.0~4.4
11	Peel strength		N/5cm≥	80			100
12	Dry Sieve Size O90		mm	≤0.1
13	Vertical permeability coefficient		cm/s	≤0.2
14	anti acid and alkaline		%	Breaking Strength remain 90%,Breaking Elongation remain 90%
