Warp Knitted Polyester PET Biaxial Uniaxial Geogrids For Road Construction

Product Description

          Warp Knitted Polyester PET Biaxial Uniaxial Geogrids Coating With PVC For Road Construction

1, Description:
EltGrid-PETG polyester geogrid adopts high strength, high modulus,and low shrinkage twisting industrial polyester fiber as
raw material.It is warp knitted with oriented structure and in the condition of no bending among warp and weft direction.
Its crossing points are bundled and bended together by high strength long polyester fiber forming tough conjunction.
Then it forms into mesh size product after coated with high quality oil or water-soluble PVC

2,Product Features:
1). High strength, high modulus and low elongation.
2). Aging resistance and high tensile strength.
3). Pre-designed and easily combing with gravel and soil.

Main Specification:
1), Tensile Strength: 20KnX20Kn to 1300KnX1300KN
2), Mesh size:12.7mmX12.7mm/25.4mmX25.4mm
3), Coating: PVC
4), Roll size: 3.95mX50/100m, 5.8mX50/100m

3, Production Process:

4,Specification:
1) Biaxial/Bx Type

2) Uniaxial/UX Type

5, Packing:

Normal packing is Width 3.95M X Length 50M/100m Per Roll In PE Film Bag

Or Width 5.8M X Length 50M/100m Per Roll In PE Film Bag

6,Test:

7, Application:

1).Strengthening soft roadbed of high-class roads and high speed railways, separating different subgrade soil material.
2). Using in reclamation engineering, dam, landslides and retaining wall.
3). Enhancing various roadbeds.
4). Strengthening soft roadbed of airport.

8, Our Company:

ANHUI ELITE INDUSTRIAL CO.,LTD
ELITE was established in 2007, has become one of the leading and professional suppliers of many kinds of Geosynthetics
(Geotextile,Geomembrane, Geogrid,Geocell, GCL,Geocomposite) in the world market.

ELITE equipements are mainly import from Germany, Italy, Cabada, France. We have one full set of precise testing instrument
and quality inspection team, technology research & Development team.
