Golden Mine Tunnel Support Structural Macro Synthetic Fibrillated Polypropylene Fibers
Synthetic fibrillated polypropylene fibers
,Macro fibrillated polypropylene fibers
,Tunnel Support Macro Synthetic fibers
Golden Mine Tunnel Support Used Structural Macro Synthetic PP Fiber Shotcrete Fibre
1, Description:
ELT-TWIST This newer class of fibers has emerged over the last 15 years as a suitable alternative to steel fibers when dosed properly.
Typical materials include polypropylene and other polymer blends with the same physical characteristics (e.g., length, shape) as steel fibers.
These fibers can be dosed from 3 to 20 lbs/yd (1.8 to 12 kg/m3).
ELT-TWIST is a 100% virgin blended copolymer synthetic Structural macro-fiber successfully used as an alternate to steel fibers, welded wire mesh
and conventional reinforcing bars in a wide variety of secondary reinforcement applications.
Benefits and characteristics
- It has the common advantages of steel fiber and synthetic fiber.
- Excellent dispersion
- It is suitable for both dry spray and wet spray process.
- Improving toughness and durability of concrete
- Improve the strength of concrete and prevent rebound
- Alkali and acid resistance, no rust, not easy to corrosion
- Lower dosage and lower use cost
- The surface does not need to be trimmed, and the operation is safe and easy.
2, Production Process
3, Specification:
| Density(g/cm 3 ) | 0.91 +/- 0.01 | Equivalent Dia(mm) | 0.3±0.05 |
| Shape | twist | break tensile Ratio(%) | 8-15 |
| Crack Ratio (%) | 20+/-5 | Melting point ( C. Deg) | 160-170 |
| Tensile Strength (Mpa) | 500 to 800 | Water Absorption | Negligible |
| Elastic Modulus (Mpa) | >3500 | Resistance to acid & alkali | Excellent |
| Material | Virgin Copolymer/Polypropylene | ||
| Length(mm) | 38/48 /54 or as per your request | ||
| Dosage rates will vary depending upon the reinforcing requirements and can range from 2kg/m³ to 5 kg/m³ | |||
4, Packing:
| Shape | Inner Packing(PE Film Bag) | Outer Packing(Plastic Woven Bag) | 20’gp | 40’HQ |
| Twist | 0.5/1.0kg | 10kg | 5500kg | 12000kg |
| Inner Packing(Water Soluble Paper Bag) | Outer Packing (Carton) | |||
| 0.5/1.0kg | 10kg | 4000kg | 9000kg | |
| Other Packing Can As Per Your Request | ||||
5,Application:
- Slab on grade.
- Elevated slabs.
- Parking areas.
- Stamped concrete.
- Pre-cast concrete.
- Water tanks.
- Pavements.
- Shotcrete.
- Renders.
- Composite decks
- Upper concrete layer - parking decks etc.
- Concrete products
- Hall floors
- Agricultural construction
- l Operational areas
6, CERTIFICATE:
Our Fibers was made by 100% Virgin Material with advanced equipment of yard and cutting, we have one full set of precise testing
instrument, testing equipment and quality inspection team, technology research and development team. the management system
was certified by ISO9001 and our products have been passed the CE Certification.
